Crossover Ladder
The most important factor for the Crossover Ladder is the clearance height and the clearance width.
It can be used to cross over conveyor systems and pipes or any other type of obstruction. It can also be used on roof surfaces.
Different Types of Finishes – Powder Coated Finish: Painted Enamel Finish: Polished Finish: Galvanized Finish.
If none of the specifications meet your requirements, just contact us directly, so we could customize your request.
- Steel or Aluminum Construction
- Platform heights, widths, and depths vary
- 300 lb capacity (additional capacity optional)
- Standard handrails are 36″H
- 42″ Handrails are available – Cal OSHA package
- The steps are 24″W by 7″D
- The stairs have a 57 degree angle
- Perforated or Grip Strut Tread (Other Options Available)
- Standard gray industrial enamel finish
~ MEETS OSHA AND ANSI STANDARDS ~
| PART | PLAT HEIGHT | PLAT (WxD) | CLEAR (HxW) | BASE (WxD) | WEIGHT |
|---|---|---|---|---|---|
| USCO4035 | 40" | 24"x35" | 37"x21" | 26"x75" | 84 lbs |
| USCO4042 | 40" | 24"x42" | 37"x28" | 26"x82" | 89 lbs |
| USCO4049 | 40" | 24"x49" | 37"x35" | 26"x89" | 96 lbs |
| USCO5035 | 50" | 24"x35" | 47"x21" | 26"x91" | 145 lbs |
| USCO5042 | 50" | 24"x42 | 47"x28" | 26"x98" | 151 lbs |
| USCO5049 | 50" | 24"x49" | 47"x35" | 26"x105" | 160 lbs |
| USCO6035 | 60" | 24"x35" | 57"x21" | 26"x103" | 180 lbs |
| USCO6042 | 60" | 24"x42" | 57"x28" | 26"x110" | 186 lbs |
| USCO6049 | 60" | 24"x49" | 57"x35" | 26"x117" | 199 lbs |
